Wolf HV300 Horizontal Wrapper

Wolf HV 300 Horizontal Wrapper

click for full size image

Specifications

Operation: The integrated infeed conveyor has carrying lugs which move the product toward the bag forming section of the machine. As a bag is formed using film from rollstock the longitudinal seal of the bag is made to form a tube of film. The film comes from the below or above the conveyor. A bottom seal has been made just prior to transporting the product into the film tube. As the product is inside the film tube, the film is advanced, a top seal is made and the finished bag is cut off from the next one to be filled. A short discharge conveyor transports the finished bag away from the sealing area for further packaging.

Technical Data:

Bag width: 10 - 300 mmPower supply: 400 V, 3 Ph, 60 Hz
Bag length: 30 - 500 mmEnergy requirem.: 4.5 kW
Bag height: 0 - 100 mmProtection class: IP 54
Film reel diam.: 400 mmAir requirem.: 30 Nl/min at 6 bar
Performance*: 250 bpmWeight: 900 kg
*Depending on product and filmColor: Ivory, RAL 1013
